HX4E/MX8A Series Voice Gateway User Manual
New Rock Technologies, Inc. 39
Name
Description
Message waiting
indication (MWI)
Choose the lighting method of message waiting indicator of voice mail here: None,
Polarity reversed, FSK, high voltage lighting.
Message waiting indicator refers to the special LED on a phone, working with voice
mail function. When user receives a voice message. The gateway will light this lamp
upon receiving the notice from platform; the light goes off when there’s no unheard
mail. It’s essential to understand whether the phone supports the indicators and lighting
method when selecting the lighting method.
Distinctive
Alert/Ringing
Set the parameter Alert-Info n according to the “Alert-Info” value provided on the SIP
server. When the “Alert-info” value of received INVITE message matches with the
Alert-Info n, ring cadence n is activated.
Alert-Info 1
To match with ring cadence 1.
Configure ring
patterns for ring
cadence 1
Configure ring patterns for ring cadence 1. It is used with
E.g 1: if the ring patterns are set to 2, 500, 500, 1000, 3000, the ringing cadence is 0.5s
on, 0.5s off; 1s on, 3s off.
E.g 2: if the ring patterns are set to 2000, 4000, the ringing cadence will be 2s on, 4s
off.
Alert-Info 2
To match with ring cadence 2.
Configure ring
patterns for ring
cadence 2.
Configure ring patterns for ring cadence 2. It is used with Alert-Info 2.
Alert-Info 3
To match with ring cadence 3.
Configure ring
patterns for ring
cadence 3
Configure ring patterns for ring cadence 3
Alert-Info 4
To match with ring cadence 4.
Configure ring
patterns for ring
cadence 4
Configure ring patterns for ring cadence 4. It is used with Alert-Info 4.
2.5 Trunk
2.5.1 Phone Number
Only a gateway with FXO ports can display this interface.
After login, click Trunk > Phone number tab to open the configuration interface.
