User Manual HX4E/MX8A Series Voice Gateway
12 www.newrocktech.com
Table 1-4 Description of HX4E Back Panel
No.
Description
PWR
Power interface, 12 VDC input
WAN
10/100 M Ethernet Interface, RJ45
PC
10/100 M Ethernet Interface, RJ45
FXO/FXS
FXS port or FXO port
Table 1-5 Indicator Status of HX4E
Indicator
Status
Description
PWR(green)
Green Flashing
The device is starting.
Steady green
The device is running.
Off
The device is powered off or a power supply fault occurs.
STU
(red, green)
Steady red
The WAN interface does not acquire the IP address. Possibly the
WAN interface is not connected to a network cable, the WAN
interface address fails to be acquired by using DHCP, the IP
addresses are conflicted, and the PPPoE dialing fails.
Red flashing
The device is starting or the Kupdate is upgrading.
Steady green
Registration is successful.
Blinking
alternatively
between red and
green
Registration failed.
Green flashing
Calling.
Off
Registration has not started.
WAN
(green)
Steady green
A WAN connection is established without any service flow.
Green flashing
A WAN connection is established with service flow.
Off
WAN interface is disconnected.
PC
(green)
Steady green
A link is connected without any service flow.
Green flashing
A service flow is being transmitted.
Off
A link is not connected.
FXS/FXO
(green)
Steady green
Off-hook or call established
Green flashing
Ringing on incoming call
Off
The port is in idle status
1.3.2 MX8A
The MX8A adopts a compact metal structural design. It can be placed on a desk or installed in a standard
communications cabinet and provides eight analog ports. MX8A supports the following types of
configuration.
