User Manual HX4E/MX8A Series Voice Gateway
42 www.newrocktech.com
Name
Description
Note:
The following features are valid only in SIP protocol. When the gateways use MGCP protocol, the control of
all call services is provided by the proxy server without the need of these setting.
Inbound handle
The gateways provide three scenarios for handling incoming calls on the FXO trunk:
 Binding: when a telephone call comes to the FXO port, the gateways will route the
call to a FXS port according to the DID number bound with the port. Note: Setting a
number to be bound is required or this setting is invalid.
Note: Setting a number to be bound is required or this setting is invalid.
 Second-stage dialing: when a telephone call comes to the Line port, the gateways
will provide the second dial tone and route the call according to the extension number
entered. Dialing tone or voice prompt file can be changed by user.
 Direct: the gateways will route the incoming call on FXO port n to FXS port n.FXO
ports map to FXS ports. For example, a call made to the first FXO port is forwarded
to the first FXS port.
Note: Direct applies only to a device having both FXO and FXS ports.
RFC6913
If this item is selected, the Fax over IP label carried in INVITE is supported.
Registration
subscription
The device periodically sends subscription messages to the SIP server. The period of
sending the subscription messages is the same as the Registration expiration in
Basic > SIP.
Polarity reversal
signal detection
If a PSTN line supports reverse polarity, make the selection here. Or this setting is
invalid. By default, this is not selected.
Caller ID
detection
Select to enable the detection function of caller ID for this FXO port. By default, this is
not selected.
Outgoing call
barring
Select if this FXO port bars outgoing call service to the PSTN. By default, this is not
selected.
Echo cancellation
Select if echo cancellation is enabled for this FXO (Line).By default, this is selected.
Connect signal
delay
After making an outgoing call from a FXO port, the gateway will send a 200 OK
message to the platform with a delay if this parameter is selected. If unselected, the
system sends a 200 OK message to the platform after off hook on the FXO port. Also
see Answer delay on page Trunk > Advanced.
Permanent
recording
Select if recording service is activated, and by default this is not selected.
2.5.3 Trunk Batch (Unavailable in the HX4E)
Only a gateway with FXO ports can display this interface.
After login, click Trunk > Batch to open the configuration interface.
Step 1
Click , the following interface is shown. Choose batch configured trunks and click
OK
.
Step 2
Click to activate this function to configure this parameter. For details of the parameter, see
Trunk > Feature
.
