HX4E/MX8A Series Voice Gateway User Manual
New Rock Technologies, Inc. 41
Figure 2-21 Trunk Line Features Configuration Interface
Table 2-15 Configuration Parameters of Trunk Features
Select a trunk line required to configure. “FXO-n” corresponds to the Trunk > Phone
number > ID n.
Display phone number associated with the trunk set in Trunk > Phone number
Set the port used for receiving and sending SIP messages on the line.
If this parameter is not specified, the local port configured in Basic > SIP is used.
This parameter is displayed only when multi port is selected in page Advanced > SIP.
Select if this trunk registers with the SIP registration server. By default, this is not
selected.
If Registration is selected, the authentication password for register of this line must be
entered here.
