HX4E/MX8A Series Voice Gateway User Manual
New Rock Technologies, Inc. 65
Set the IP address and port number of session border proxy server. The character of “:”
must be used between IP address and port number.
Server address could be set into IP address or domain name. When a domain name is
used, it is required to configure DNS server on the "Basic > Network" page. Example:
201.30.170.38:1020 or sbc.com:1020.
Signaling port assignment of the gateway, the default value is 4660. Signaling port
number may be set at will, but cannot conflict with other ports of equipment.
2.7.10 Greeting
After login, choose Advanced > Greeting to open the audio files interface.
Figure 2-37 Greeting Interface
Table 2-30 Greeting Configuration Parameters
Second Stage
Dialing
Configuration
Click Browse, and then select the local audio file named welcome.wav. Click
Upload. The uploaded audio file overwrites the original one.
If you want to delete the current customized second stage dialing tone, click Delete.
After the gateway restarts, the default second stage dialing tone is used.
Click Browse, and then select the local audio file named fring1/2/3/4/5/6/7/8/9.wav.
Click Upload. The uploaded audio file overwrites the original one.
If you want to delete the current color ringback tone, you can click Delete. After the
gateway restarts, the default color ringback tone is used.
2.7.11 Call Progress Tone Plan
After login, click the label of Advanced > Tones to open this interface.
