User Manual HX4E/MX8A Series Voice Gateway
40 www.newrocktech.com
Figure 2-20 Phone Number Configuration Interface
Table 2-14 Configuration Parameters of FXO Phone Number
This number is used for the fast setup of consecutive number of trunk line. Click Batch
after filling in initial number, the number of Line 1 adopts initial number; that of Line 2
increases 1 progressively based on that of Line 1, and so on. You needn’t fill in if you
do not use batch configuration or the number is not consecutive.
Fill in the telephone number associated with the trunk n (FXO port). This should be
manually performed if Batch mode is not used.
2.5.2 Trunk Features
Only a gateway with FXO ports can display this interface.
After login, click Trunk > Trunk tab to open the configuration interface.
