18 – ENGLISH
5.4.1 Learning in automatic mode
L3
L4
45
To effect the automatic learning procedure:
1. simultaneously press and hold the and
g
buttons
h
2. release the buttons when LEDs “L3” and “L4” start
ashing quickly (after roughly 5 seconds)
3. check that the automation carries out the following
manoeuvre sequences:
a. slow closing of motor M1 up to the mechanical stop
b. slow closing of motor M2 up to the mechanical stop
c. slow opening of motor M2 and of motor M1 up to the
stop
d. fast closing of motors M1 and M2.
m
If the rst manoeuvre (a) fails to close the leaf
controlled by motor M1 but closes the one
controlled by M2, press
f
or
h
to
stop the learning phase. At this point, reverse the
connections of motors M1 and M2 on the terminals
on the control unit and those of the respective
encoders. Then repeat the self-learning procedure.
m
If the rst two manoeuvres (a and b) are not “closing”
but “opening” manoeuvres, press the
f
or
h
button to stop the learning phase. At this
point, invert the control wires (external positions
with respect to the terminal) on the motor that
executed the opening manoeuvre and repeat the
self-learning procedure.
4. at the end of the closing manoeuvre (d) of the two motors,
LEDs “L3” and “L4” switch off to signal that the procedure
was performed correctly.
m
If, during the automatic learning procedure, the
photocells or one of the devices connected to the
“stop” input intervene, the procedure interrupts and
LED L1 starts ashing. In this case, the self-learning
procedure must be repeated from the beginning.
l
The automatic learning procedure can be run
again at any time, even after the installation phase;
for example, after modifying the position of the
mechanical stops.
5.4.2 Learning in manual mode
m
The user has maximum 10 seconds to press
the buttons consecutively during the learning
procedure. After this time, the procedure terminates
automatically and memorises the changes made up
to that time.
L3
L4
46
l
When LEDs "L1..L8" ash, to shift between LEDs
simply press the
f
or
h
button briey
(the LED will ash to signal the current position).
l
While LEDs "L1..L8" ash, to move the motor in any
one direction, it is necessary to press and hold the
f
or
h
button.
To effect the manual learning procedure:
1. simultaneously press and hold the and
g
buttons
h
2. release the buttons when LED “L1” starts ashing (after
roughly 3 sec)
3. LED “L1” ashes: position 0 of M1
– to command and move motor 1 to position “0” (“Figure
44”): press and hold the
f
or
h
button.
Once the position is reached, release the button to stop
the manoeuvre
– to memorise the position, press and hold the
g
button for at least 3 seconds then release it (after 2
seconds LED “L1” will remain lit and after the
g
button is released, LED “L2” will start ashing)
4. LED “L2” ashes: position 0 of M2
– to command and move motor 2 to position “0” (“Figure
44”): press and hold the
f
or
h
button.
Once the position is reached, release the button to stop
the manoeuvre
– to memorise the position, press and hold the
g
button for at least 3 seconds then release it (after 2
seconds LED “L2” will remain lit and after the
g
button is released, LED “L3” will start ashing)
5. LED “L3” ashes: position SA of M2
– to command and move motor 2 to position “SA”
(“Figure 44”): press and hold the
f
or
h
button. Once the position is reached,
release the button to stop the manoeuvre
– to memorise the position, press and hold the
g
button for at least 3 seconds then release it (after 2
seconds LED “L3” will remain lit and after the
g
button is released, LED “L4” will start ashing)
