TECHNICAL SPECIFICATIONS
12
11 TECHNICAL SPECIFICATIONS
l
All technical specications stated in this section refer to an ambient temperature of 20°C (± 5°C). Nice S.p.A.
reserves the right to apply modications to the product at any time when deemed necessary, without altering
its functions and intended use.
Table 15
TECHNICAL SPECIFICATIONS
Description Technical specication
HK7024 HK7224 HK7024HS HK7224HS
Product type
Electromechanical gearmotor for
automatic gate and door systems with
direct-current motor, epicyclic gear
reducer and mechanical unlocking
mechanism. Incorporated control unit and
OXI radio receiver
Electromechanical gearmaotor for
automatic gate and door systems with
direct-current motor, epicyclic gear
reducer and mechanical unlocking
mechanism.
Peak torque [corresponding to the ability to
develop a force capable of moving the leaf]
500 Nm
Nominal torque [corresponding to the ability
to develop a force capable of keeping the
leaf moving]
120 Nm
No-load speed (the control unit allow for
programming 6 speeds roughly equal to:
100, 85, 70, 55, 45, 30%)
1,5 rpm 2 rpm 1,5 rpm 2 rpm
Maximum frequency of operating cycles (at
nominal torque)*
40 cycles/hour
Maximum continuous operating time (at
nominal torque)**
7 minutes
Application limits
The product can be
used on gates with
leaves weighing
up to 330 kg or for
lengths up to 3,5 m
The product can be
used on gates with
leaves weighing
up to 270 kg or for
lengths up to 3 m
The product can be
used on gates with
leaves weighing
up to 330 kg or for
lengths up to 3,5 m
The product can be
used on gates with
leaves weighing
up to 270 kg or for
lengths up to 3 m
Durability
Estimated between 150.000 cycles and 500.000 cycles, depending on the conditions
specied in the “Product durability” paragraph.
Power supply HYKE 230Va (±10%) 50/60 Hz 24Vc (±10%)
Emergency power supply
With optional accessory PS124 -
Solar panel power supply
Conguration for SYKCE kit -
Maximum power draw at nominal torque
300 W 140 W
Maximum current draw
1,5 A (3 A for version HK7024K/V1) 6 A for maximum 2 s
Power draw in “Stand-by-All” mode with
power supply from PS124 or SYKCE kit
(including OXI receiver)
Below 30 mW -
Warning light output***
One LUCYB warning light (12 Vc, 21 W)
lamp
-
Electric lock output*** One 12 Va max 15 VA electric lock
-
Gate open indicator output***
One 24 V lamp maximum 4 W (the output
voltage can vary between -30 and +50%,
the output can also control small relays)
-
BLUEBUS output
One output with maximum load of 15
Bluebus units
(maximum 6 pairs of photocells, e.g.
EPMB or EPLB, plus 2 pairs of photocells
addressed as opening devices plus
maximum 4 EDSB or ETPB control
devices)
-

Nice HK7024 Specifications

General

Brand	Nice
Model	HK7024
Category	Gate Opener
Language	English
