12 - FORM NO. 56043098 - Convertamatic
™
24, 26, 28, 32 / BA 625, 725, 825
KNOW YOUR MACHINE
DESCRIPTION OF INDICATORS ON THE CONTROL PANEL:
In general, the following guidelines apply to the control panel indicators:
A fl ashing green or yellow indicator means that a fault has occurred in the particular system. An example of this would be an over-current fault.
A yellow indicator means that the particular function has been enabled but is not currently on. For example, if a scrub mode is selected and the
throttle is in neutral, the scrub system, vacuum, and solution indicators will all be yellow indicating that the systems are enabled and ready to turn
on when the throttle is moved to forward or reverse.
A green indicator means that the particular system is on.
A fl ashing green indicator means that the particular system is in a delayed-off condition. An example of this is when a scrub mode is selected and
the throttle goes from forward or reverse to neutral. When this happens the vacuum indicator will fl ash green indicating that the vacuum is still on but
that it will be turning off after the delay period.
Scrub OFF Indicator (J):
• This indicator will be green if the scrub system is off and ready to be activated.
• This indicator will be red if the scrub system has been turned off and the scrub deck is not up yet.
• This indicator will fl ash red if there is a fault in the scrub system.
• This indicator will be off if the scrub system has been activated.
Regular Scrub ON Indicator (K):
• This indicator will be yellow if the scrub system is enabled in “Regular” scrub mode but the drive paddle is in neutral.
• This indicator will be green if the scrub system has been turned on in “Regular” scrub mode and the machine is moving in either direction.
• This indicator will be off if the scrub system has been turned OFF.
Heavy Scrub ON Indicator (L):
• This indicator will be yellow if the scrub system is enabled in “Heavy” scrub mode but the drive paddle is in neutral.
• This indicator will be green if the scrub system has been turned on in “Heavy” scrub mode and the machine is moving in either direction.
• This indicator will be off if the scrub system has been turned OFF.
Extreme Scrub ON Indicators (K & L):
• Both of these indicators will be yellow if the scrub system is enabled in “Extreme” scrub mode but the drive paddle is in neutral.
• Both of these indicators will be green if the scrub system has been turned on in “Extreme” scrub mode and the machine is moving in either
direction.
Control panel LED Display (D):
See the detailed drawing shown in the Know Your Machine manual section for the specifi c description of the individual icon symbols. NOTE: If a
speed control fault occurs (error code 3) the wand indicator will fl ash the fault code produced by the Curtis speed control. Refer to the service manual
troubleshooting section for details.
Wand Switch Indicator (M):
• This indicator will be green if the Wand Switch has been turned ON.
• This indicator will be off if the Wand Switch has been turned OFF.
Vacuum System Indicator (N):
• This indicator will be green if the vacuum is on.
• This indicator will fl ash green if the vacuum is in the 10 second delayed-off condition.
• This indicator will be yellow if the vacuum is enabled but the drive pedal is in neutral.
• This indicator will fl ash yellow if there is a vacuum system fault.
• This indicator will be off if the vacuum is disabled and turned off.
Solution System Indicator (O):
• This indicator will be green if the solution is on.
• This indicator will be yellow if the solution is enabled but the drive paddle is in neutral.
• This indicator will fl ash yellow if there is a solution system fault.
• This indicator will be off if the solution is disabled and turned off.
Chemical “AXP / EDS” System Indicator (P):
• This indicator will be green if the AXP / EDS system is on.
• This indicator will be yellow if the AXP / EDS system is enabled but the drive paddle is in neutral.
• This indicator will be off if the AXP / EDS system is disabled and turned off.
Extended Scrub System Indicator (Q):
• This indicator will be green if the Extended Scrub system is on.
• This indicator will be yellow if the Extended Scrub system is enabled but the recovery tank switches haven’t been activated.
• This indicator will be off if the Extended Scrub system is disabled and turned off.
revised 5/07
