Installation
3-13
Part 1089210A04
E 2010 Nordson Corporation
The blower and duct size for each application will depend on many
variables. Size all blowers to accommodate all losses in the ductwork and
ensure that the specified air flow and pressure for each lamphead is
maintained.
1114
(4.488)
150
(5.906
117.80
(4.638)
53.4 (2.10): 2 in. Focus Reflectors
78.75 (3.1): 3 in. Focus Reflectors
200.5 (7.894)
205.80 (8.102)
267.0 (10.512)
373.35
(14.699)
150.0
(5.906)
64.7
(2.547)
150
(5.906)
Typ. 3 sides
M5 Screws
(Typ. 3 sides)
65.0 (2.559)
114.0
(4.488)
Pressure Port *
Port *
18.25 (0.719)
76.0 (2.992)
9.50 (0.374)
182.0
(7.165)
76.0 (2.992)
76.0 (2.992)
Unicable
Receptacle
* DO NOT BLOCK EXTERNAL PORTS
WHEN MOUNTING LampheadS
Figure 3-6 Lamphead Dimensions − External Blower
