Operation
4-3
Part 1089210A04
E 2010 Nordson Corporation
DescriptionControlItem
9 Digital Display Displays power levels, operation and fault messages.
10 POWER SETPOINT Displays the percentage power output as controlled remotely and of the
actual power level set on the unit.
11 Nordson Oval
(System Configuration)
Sets up power supply configuration parameters. Refer to Table 3-4 in the
Installation section for more information.
Additional Functions
Temperature
Internal temperatures of the lamphead and power supply can be displayed
by pressing the OFF and SET-SAVE buttons simultaneously:
LH xxC = Lamphead Internal Temperature
LB xxC = Lamphead Circuit Board Temperature
MB xxC = Power Supply Control Board Temperature
Light Detector
The relative bulb output intensity can me monitored by pressing the DOWN
ARROW and STANDBY buttons simultaneously.
Sensor Saturation = 920 counts
Alarm Trip Point for 50% to 100% Power Level = 600 counts
Alarm Trip Point for less than 50% Power Level = 300 counts
Starter Bulb Test
The starter bulb turns on for a few seconds during lamp ignition, to help the
main UV lamp ignite. To verify that the starter bulb is functional, it can be
turned on manually by pressing LOCAL for approximately 20 seconds.
Panel Lock
NOTE: For use with systems operated in remote modes.
All front panel control functions can be locked out by pressing REMOTE for
approximately 20 seconds. The display will momentarily display LOCK.
The period at the left of the display will remain on as long as the system is
locked. To unlock the system press REMOTE for approximately 20
seconds. UNLOCK will display and the unit will return to the normal
operation state.
