Nordson CoolWave 2 - CW-2 Lampheads

Parts
7-4
Part 1089210A04
E 2010 Nordson Corporation
CW-2 Lampheads
See Figure 7-2.
Item Part Description Quantity Note
1 1074677 LAMPHEAD, focus, 2.1, external 1
1 1075554 LAMPHEAD, focus, 3.1, external 1
1 1075555 LAMPHEAD, flood, external 1
1 1083279 LAMPHEAD, focus, 2.1, internal 1
1 1083291 LAMPHEAD, focus, 3.1 internal 1
1 1083293 LAMPHEAD, flood, internal
2 1051462
S BULB, UV, microwave, CW410, H (Mercury)
1 A, B
2 1051463
S BULB, UV, microwave, CW410, D, (Iron)
1 A, B
2 1051464
S BULB, UV, microwave, CW410, V (Gallium)
1 A, B
2 1051465
S BULB, UV, microwave, CW410, Q (Indium)
1 A, B
2 1051467
S BULB, UV, microwave, CW410, H+ (Mercury
Plus)
1 A, B
2 1051468
S BULB, UV, microwave, CW410, M (Lead)
A, B
3 775060
S BRACKET, retaining reflector, focus, PR, kit,
CW10
2
3 775061
S BRACKET, retaining reflector, flood, PR, kit,
CW10
2
4 1077320
S LIGHT DETECTOR, kit
1 B
5 1079419
S TRANSFORMER, filament, kit
2 B
6 775040
S BULB, starter, kit, CW10/6
1 B
7 775090
S REFLECTOR, focus, 2.1, standard, kit, CW10,
each
2 B, C, D
7 775092
S REFLECTOR, focus, 3.1, kit, CW10, each
2 B, C, D
7 775100
S REFLECTOR, flood, standard, kit, CW10
2 B, C, D
8 775115
S DEFLECTOR, strip, quartz, kit, CW10
1 B
9 775120
S SCREEN, lamphead, kit, CW10
1 B
10 1075164
S MAGNETRON PAIR, 3.0 Kw, kit
1 B
11 - - - - - -
S SCREW, M4 mounting holes
8
12 - - - - - -
S PAN HEAD SCREW, M4 x 8, Phillips, steel,
zinc plated
14
13 - - - - - -
S PAN HEAD SCREW, M4 x 8, Phillips with lock
washer, steel, zinc plated
8
14 - - - - - -
S BUTTON HEAD SOCKET SCREW, M3 x 10,
with Nylok nut
4
15 - - - - - -
S BUTTON HEAD SOCKET SCREW, M3 x 5,
stainless steel
8
16 - - - - - -
S PAN HEAD SCREW, M5 x 8, Phillips, steel,
zinc plated
3
17 - - - - - -
S SCREW, M5 mounting holes
12
18 1053767
S REFLECTOR BULB MOUNTING, focus, 2.1,
glass, kit, CW10
1 D
18 1053768
S REFLECTOR BULB MOUNTING, focus, 3.1,
glass, kit, CW10
1 D
18 1053769
S REFLECTOR BULB MOUNTING, flood, glass,
kit
1 D
Continued...
