CW-2 Power Supplies
Part Description Note
60 Hz Applications:
1088208 Power Supply, 480V, int blower, no DeviceNet
1088236 Power Supply, 480V, int blower, no DeviceNet, wood shipping crate
1088203 Power Supply, int blower
1088237 Power Supply, 480V, int blower, wood shipping crate
50 Hz Applications:
1088234 Power Supply, 400V, int blower, no DeviceNet, boxed
1088231 Power Supply, 400V, int blower, no DeviceNet
1088235 Power Supply, 400V, int blower, boxed
1088206 Power Supply, 400V, int blower
NOTE A: Recommended for power supplies shipping outside the USA.
Repair Parts
See Figure 7-1.
Item Part Description Quantity Note
− - - - - - - 50/60 HZ POWER SUPPLY, CW2 1
1 1077135
S CONNECTOR, I/O board, kit, CW2
1
2 1077121
S TRANSFORMER, HV, kit, CW2
2
3 1089207
S TRANSFORMER, step down, kit, CW2
1
NS 1089208
S MEMBRANE, kit, CW2
1
4 1091465
S FUSE, kit, CW2
1 A, B
4a - - - - - -
SS FUSE, 30 amp
3 B
4b - - - - - -
SS FUSE, 10 amp 250 volt
2 B
4c - - - - - -
SS FUSE, 160 ma, 250 volt
1 B
4d - - - - - -
SS FUSE, 2 amp, 250 volt
1 B
5 772214
S FAN, 6 in x 1.5 in, 240 VAC
2 A
6 1101815
S MAIN CONTROL BOARD, kit, CW2
1
7 775142
S PCB, display, kit CW10
1
8 1102449
S PHASE CONTROL BOARD, kit, CW2
1
9 1077131
S I/O CONNECTOR BOARD, kit, CW2,
with DeviceNet
1
9 1083974
S I/O CONNECTOR BOARD, kit, CW2,
without DeviceNet
10 1077128
S DIODE, HV, kit, CW2
2
11 - - - - - -
S SCREW, M5 x 10
10
12 1086731 DETECTOR, RF, kit, CW 1
NS 1089206 HARNESS, power supply, unicable, internal, kit 1
NOTE A: Recommended spare part. Keep this part in inventory to avoid unplanned downtime.
B: Fuse kit 1091465 contains three 30 amp, 500 volt main fuses; two 10 amp, 250 volt fuses for the step
down transformer; one 160 microamp, 250 volt control board fuse; one2 amp, 250 volt fuse for the
filament transformer.
NS: Not Shown
