Parts
7-7
Part 1089210A04
E 2010 Nordson Corporation
RF Detector
Part Description Note
1086731 Detector, RF A
NOTE A: Refer to System Cables on page 7-6 for RF Detector cables.
External Blowers
Item Part Description Quantity Note
NS 775162 60 Hz BLOWER, external, 60 Hz (single lamp) 1
NS 775165 50 Hz BLOWER, external, 50 Hz (single lamp) 1
NS: Not Shown
Reflector Conversion Kits
NOTE: The following kits are used with CW610 and CW 410 lampheads.
Part Description
1053793 KIT, reflector conversion, 2.1 focus, CW10
1053794 KIT, reflector, conversion, 3.1 focus, CW10
1053795 KIT, reflector conversion, flood, CW10
Accessories
Part Description
AirShieldt Ventilation System − Captures the heated exhaust air from the lamphead and exhausts it to a separate
exhaust duct.
775055 KIT, duct, exhaust, CW10, encl, quartz (for CW-410/CW-610T lampheads)
1068608 KIT, duct, exhaust, deep, CW10, encl, quartz (for CW-410/CW-610T lampheads using a bottom
pressure port)
LiteTitet Shutter System − A pneumatically powered shutter opens and closes instantly to block UV light without
turning off the lamphead or power supply.
775198 KIT, shutter, LH, CW10
