Specifications
8-1
Part 1089210A04
E 2010 Nordson Corporation
Section 8
Specifications
Power Supply
Table 8-1 Standard and Enclosure Mounted Power Supply Specifications
Item Specification
Dimensions
length 753 mm (29.65 in.)
width 465.5 mm (18.33 in.)
height 256.3 mm (10.09 in.)
Weight 118 kg (260 lb)
Voltage
440/480 Vac, 3, @ 60 Hz or 380/440 Vac, 3, @ 50 Hz
Current Refer to Table 8-2
Environmental Operating Conditions
Ambient Temperature
5−40 _C (41−104 _F)
Altitude Up to 2000 meters (6561 ft)
Rh
80% up to 31 _C (88 _F), decreasing linearly to 50% at 40 _C (104 _F)
Ingress Protection Rating IP−21
RF Detector
Max. Temperature
60 _C (140 _F) Ambient
Table 8-2 Power Line Current for 410I Internal Blower
Line
60 Hz 50 Hz
Amps @ 440 Vac Amps @ 480 Vac Amps @ 380 Vac Amps @ 440 Vac
L1 11 10 15 15
L2 16 15 22 21
L3 12 11 16 16
