Nordson CoolWave 2 - Fuse Identification and Replacement

Maintenance
5-2
Part 1089210A04
E 2010 Nordson Corporation
Fuses
See Figures 5-1 and 5-2 to identify the replaceable fuses in the power
supply.
Use an appropriate tool to remove the fuses. Replace them with identical
fuses. Refer to the Parts section for ordering information.
S F1: Blower
S F2: Blower
S F3: Board Power
S F4: Bulb Filament
Fuse F3
160 mA
Fuse F1
3 A
Fuse F2
3 A
Fuse F4
2 A
Figure 5-1 Main Control Board Fuses
