Specifications
8-3
Part 1089210A04
E 2010 Nordson Corporation
Lamphead
Table 8-3 Lamphead Specifications
Item Specification
Dimensions
length
width
264.50 mm (10.41 in.)
201.00 mm (7.91 in.)
height 435.10 mm (17.13 in.)
Weight With External Blower − 19 kg (42 lb), With Internal Blower − 25 kg (55lb)
Cooling Air 315 cfm @ 5.5 in. W.C.; measured at lamphead (9.9 mm
3
@ 1780 Pascal)
Reflector Glass with a proprietary coating 220−470 nm; focus/flood profiles
Focal Length 2.1, 3.1, and flood
Interlocks Light on detector
Cooling air sensor
Unicable detection
RF leakage detection
Bulb
Table 8-4 Bulb Specifications
Item Specification
Length 254 mm (10 in.)
Power 400 watts/in. maximum
Types Mercury, Mercury +, Iron, Gallium, Indium, Lead
System Schematics
