Operation
4-1
Part 1089210A04
E 2010 Nordson Corporation
Section 4
Operation
WARNING: Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
Introduction
Startup procedures will vary depending on how the UV system was
integrated into other systems and equipment. As a result, the startup
procedures documented in this manual are strictly for the UV equipment.
Display and Controls
See Figure 4-1 and Table 4-1.
1
2
10
3
4
7
8
5
6
9
11
410I
Figure 4-1 CoolWave 2 Displays and Controls
