Nortek Signature Series User Manual

User Cases 15
© 2017 Nortek AS
4.2 Download telemetry file via FTP
In this example, a Signature1000 is set up to measure currents for 2 minutes every 10 minutes and
waves every hour (4096 samples at 4 Hz). The raw current data are processed and a subset is saved
as a telemetry file and made available on FTP.
Configuration example:
%Recommended starting point for configuration file
SETDEFAULT,ALL
OK
%Configuration for instrument:
SETPLAN,MIAVG=600,AVG=1,DIAVG=0,VD=0,MV=10,SA=35,BURST=1,
MIBURST=3600,DIBURST=0,SV=0,FN="Ex3.ad2cp",SO=0,FREQ=1000
OK
SETAVG,NC=21,CS=1,BD=0.2,CY="ENU",PL=0,AI=120,VR=2.5,DF=3,NPING=13,
NB=4,CH=0,MUX=0,BW="BROAD",ALTI=0,BT=0,ICE=0,ALTISTART=1,ALTIEND=30
OK
SETBURST,NC=13,NB=4,CS=1,BD=9.5,CY="BEAM",PL=0,SR=4,NS=4096,VR=2.5,
DF=3,NPING=1,CH=0,VR5=2.5,ALTI=1,BT=0,DISV=0,RAWALTI=1,
ALTISTART=4.8,ALTIEND=33.1
OK
%Configuration for telemetry file:
SETTMAVG,EN=1,CD=2,PD=1,AVG=120,TV=1,TA=1,TC=1,CY="ENU",FO=1,SO=0,
DF=100
OK
SAVE,ALL
OK
DEPLOY,TIME="2014-11-12 14:40:00"
OK
Go to ftp://your-IP-address to find the telemetry file (telemetryfile.bin). Here is part of the result
from the above configuration. Note that the data were collected in air.
$PNORC,091715,142440,1,0.24,-1.35,-2.21,-1.69,1.37,169.7,C,79,84,67,102,11,13,8,11*2B
$PNORC,091715,142440,3,0.64,-0.28,-1.91,-1.32,0.70,113.9,C,79,84,66,96,12,14,7,20*13
$PNORC,091715,142440,5,0.08,-0.50,-1.76,-1.48,0.51,171.2,C,78,84,66,92,11,13,7,24*1D
$PNORC,091715,142440,7,-0.37,0.97,-1.02,-1.07,1.04,339.0,C,78,84,66,67,11,14,10,10*21
$PNORC,091715,142440,9,-0.94,0.57,-0.76,-1.11,1.10,301.1,C,78,83,65,69,12,15,9,10*10
$PNORC,091715,142440,11,-0.37,0.76,-0.95,-1.06,0.85,334.0,C,78,83,65,66,13,15,8,8*14
$PNORC,091715,142440,13,0.05,-0.25,-1.64,-1.36,0.26,168.4,C,78,84,66,82,11,14,9,33*2F
$PNORC,091715,142440,15,-0.20,0.20,-1.36,-1.32,0.28,314.6,C,78,84,66,67,11,13,9,7*16
$PNORC,091715,142440,17,0.19,0.17,-1.47,-1.13,0.25,48.0,C,78,84,65,69,12,16,9,2*0D
$PNORC,091715,142440,19,-0.91,0.45,-0.90,-1.19,1.02,296.5,C,78,84,65,66,12,14,10,8*27
$PNORC,091715,142440,21,-0.49,0.66,-1.00,-1.11,0.82,323.1,C,78,84,65,67,12,14,11,10*13
$PNORI,4,Signature1000900002,4,11,0.20,1.00,0*1B
$PNORS,091715,143440,00000000,2A4C0000,14.3,1300.0,278.3,15.7,-33.0,0.000,-262.45,0,0*65

Nortek Signature Series Specifications

General

Type	Acoustic Doppler Current Profiler (ADCP)
Operating Temperature	-5°C to +45°C
Storage Temperature	-20°C to +60°C
Temperature Sensor	Integrated
Pressure Sensor	Integrated
Compass and Tilt Sensor	Integrated
Data Storage	Internal memory
Communication Interfaces	Ethernet, RS-232
Depth Rating	Up to 6000 meters (depending on model)
Data Output	ASCII, binary
Beam Angle	Varies by model
Velocity Accuracy	±0.5% of measured velocity ±1 mm/s
