Nortek Signature Series User Manual

Integrator's Guide44
© 2017 Nortek AS
5.38 SETTMBURST/GETTMBURST/GETTMBURSTLIM
Argument
Description
EN
Enable burst telemetry
NS
Number of burst samples to save
0 – Save all burst samples
1 – BURST.NS
SO
Enable Serial Output
FO
Enable File Output
DF
Data Format
ENAVG
Enable averaging
CY
Coordinate system in data output
MAPBINS
Vertical bin mapping
The actual valid range for the various parameters for the firmware version is used can be found by
using the GETTMBURSTLIM command. This command has the same arguments as the
SETTMBURST/GETTMBURST commands shown in the list above. The output format for limits is
described in Data Limit Formats.
5.39 SETTMALTI/GETTMALTI/GETTMALTILIM
Sets / gets the parameters and limits for altimeter.
Argument
Description
EN
Enable/disable altimeter telemetry
TS
Include time stamp
TQ
Include quality parameter
FO
File output
SO
Serial output
DF
Altimeter Telemetry format.
200 – NMEA (PNORA) format without Tags.
201 – NMEA (PNORA) format with Tags.
Example:
SETTMALTI,1,1,0,1,201
GETTMALTI
GETTMALTILIM

Nortek Signature Series Specifications

General

Type	Acoustic Doppler Current Profiler (ADCP)
Operating Temperature	-5°C to +45°C
Storage Temperature	-20°C to +60°C
Temperature Sensor	Integrated
Pressure Sensor	Integrated
Compass and Tilt Sensor	Integrated
Data Storage	Internal memory
Communication Interfaces	Ethernet, RS-232
Depth Rating	Up to 6000 meters (depending on model)
Data Output	ASCII, binary
Beam Angle	Varies by model
Velocity Accuracy	±0.5% of measured velocity ±1 mm/s
