Nortek Signature Series User Manual

Integrator's Guide28
© 2017 Nortek AS
5.8 SETBURSTHR/GETBURSTHR/GETBURSTHRLIM
Set/get burst HR profile settings and get the relevant limits
Argument
Description
PROC
0 - Pulse Coherent Processing using a single
Ambiguity
1 - Pulse Coherent Processing with Extended
Velocity Range (EVR)
LAG
Distance between two transmit pulses (slanted
beams)
LAG5
Distance between two transmit pulses (vertical
beam)
SCORR
Number of Ambiguities to resolve when using EVR
NC
Number of cells
CS
Cell size (m)
BD
Blanking distance (m)
PL
Power Level
5.9 SETECHO/GETECHO/GETECHOLIM
Set/get echo sounder settings and get the relevant limits
Argument
Description
NC
Number of cells
BINSIZE
Bin size
BD
Blanking Distance
DF
Data format
FREQ1
Enable and set frequency of echo gram
NBINF1
N/A - must be set to 1
XMIT1
Transmit length
PL1
Power level
PULSECOMP1
Enable Pulse Compression
FREQ2,...
...repeat for 2 and 3
Note that Pulse Compression may only be enabled for one echogram.

Nortek Signature Series Specifications

General

Type	Acoustic Doppler Current Profiler (ADCP)
Operating Temperature	-5°C to +45°C
Storage Temperature	-20°C to +60°C
Temperature Sensor	Integrated
Pressure Sensor	Integrated
Compass and Tilt Sensor	Integrated
Data Storage	Internal memory
Communication Interfaces	Ethernet, RS-232
Depth Rating	Up to 6000 meters (depending on model)
Data Output	ASCII, binary
Beam Angle	Varies by model
Velocity Accuracy	±0.5% of measured velocity ±1 mm/s
