Nortek Signature Series User Manual

Telemetry Data Formats 69
© 2017 Nortek AS
7.1.1 AWAC NMEA Format (DF=100)
Data with variants of -9 (-9.00, -999…) are invalid data.
Empty files are fields not used.
The checksum calculation is part of the NMEA standard. It is the representation of two hexadecimal
characters of an XOR if all characters in the sentence between – but not including – the $ and the *
character.
Information (configuration) $PNORI
Column
Description
Data format
Example
0
Identifier
"$PNORI"
1
Instrument type
N,
4=Signature
4
2
Head ID
Signaturexxx
xNNNNNN
Signature100
0900002
3
Number of beams
N
4
4
Number of cells
dd.dd
20
5
Blanking (m)
dd.dd
0.20
6
Cell size (m)
dd.dd
1.00
7
Coordinate system
ENU=0,
XYZ=1,
BEAM=2
0
8
Checksum
*hh
2E
Example (DF=100): $PNORI,4,Signature1000900002,4,5,0.20,1.00,0*2E
Sensor data $PNORS
Column
Description
Data format
Example
0
Identifier
"$PNORS"
1
Date
MMDDYY
102115
2
Time
hhmmss
090715
3
Error Code (hex)
hh
00000000
4
Status Code (hex)
hh
2A480000
5
Battery Voltage
dd.d
14.4
6
Sound Speed
dddd.d
1523.0
7
Heading
ddd.d
275.9
8
Pitch (deg)
dd.d
15.7
9
Roll (deg)
dd.d
-2.3
10
Pressure (dBar)
ddd.ddd
0.000

Nortek Signature Series Specifications

General

Type	Acoustic Doppler Current Profiler (ADCP)
Operating Temperature	-5°C to +45°C
Storage Temperature	-20°C to +60°C
Temperature Sensor	Integrated
Pressure Sensor	Integrated
Compass and Tilt Sensor	Integrated
Data Storage	Internal memory
Communication Interfaces	Ethernet, RS-232
Depth Rating	Up to 6000 meters (depending on model)
Data Output	ASCII, binary
Beam Angle	Varies by model
Velocity Accuracy	±0.5% of measured velocity ±1 mm/s
