Nortek Signature Series - Page 70

Integrator's Guide70
© 2017 Nortek AS
11
Temperature (deg C)
dd.dd
22.45
12
Analog input #1
Not in use
0
13
Analog input #2
Not in use
0
14
Checksum
*hh
1C
Example (DF=100):
$PNORS,102115,090715,00000000,2A480000,14.4,1523.0,275.9,15.7,2.3,0
.000,22.45,0,0*1C
Current velocity data $PNORC
Column
Description
Data format
Example
0
Identifier
"$PNORC"
1
Date
MMDDYY
102115
2
Time
hhmmss
090715
3
Cell number
N
4
4
Velocity 1 (m/s) (Beam1/X/East)
dd.dd
0.56
5
Velocity 2 (m/s) (Beam2/Y/North)
dd.dd
-0.80
6
Velocity 3 (m/s) (Beam3/Z1/Up1)
dd.dd
-1.99
7
Velocity 4 (m/s) (Beam4/Z2/Up2)
dd.dd
-1.33
8
Speed (m/s)
dd.dd
0.98
9
Direction (deg)
ddd.d
305.2
10
Amplitude unit
C= counts
C
11
Amplitude (Beam 1)
dd
80
12
Amplitude (Beam 2)
dd
88
13
Amplitude (Beam 3)
dd
67
14
Amplitude (Beam 4)
dd
78
15
Correlation (%) (Beam1)
dd
13
16
Correlation (%) (Beam2)
dd
17
17
Correlation (%) (Beam3)
dd
10
18
Correlation (%) (Beam4)
dd
18
19
Checksum
*hh
22
Example (DF=100): $PNORC,102115,090715,4,0.56,-0.80,-1.99,-
1.33,0.98,305.2,C,80,88,67,78,13,17,10,18*22
Note that the amplitude can be converted to a dB scale by multiplying by 0.50 dB/count.
