Nortek Signature Series User Manual

Commands 45
© 2017 Nortek AS
5.40 SETTMBT/GETTMBT/GETTMBTLIM
Sets / gets the parameters and limits for bottom track telemetry.
Argument
Description
EN
Enable/disable bottom track telemetry
FO
File output
SO
Serial output
DF
Bottom track Telemetry format.
300 – NMEA without tags.
301 – NMEA with tags.
302 – NMEA without tags and Sensor Data.
303 – NMEA with tags and Sensor Data.
NPING
Number of Pings
FOMTH
Figure of Merit threshold.
CY
Coordinate system
Example:
SETTMBT,1,1,1,301
GETTMBT
GETTMBTLIM
5.41 TMSTAT
This command returns the length (# of bytes) of the telemetry file.
Example:
TMSTAT<CR><LF>
13500<CR><LF>
OK<CR><LF>

Nortek Signature Series Specifications

General

Type	Acoustic Doppler Current Profiler (ADCP)
Operating Temperature	-5°C to +45°C
Storage Temperature	-20°C to +60°C
Temperature Sensor	Integrated
Pressure Sensor	Integrated
Compass and Tilt Sensor	Integrated
Data Storage	Internal memory
Communication Interfaces	Ethernet, RS-232
Depth Rating	Up to 6000 meters (depending on model)
Data Output	ASCII, binary
Beam Angle	Varies by model
Velocity Accuracy	±0.5% of measured velocity ±1 mm/s
