Nortek Signature Series User Manual

Integrator's Guide82
© 2017 Nortek AS
7.5 ASCII Data Input Using Ethernet
/* Sample code showing how to connect to and receive data from the Nortek Signature series
* of instruments using the ASCII only data port.
* Compiles on both Windows (requires ws2_32 library) and Linux.
*/
#include <stdio.h>
#include <stdlib.h>
#include <sys/types.h>
#ifdef __WIN32__
#include <winsock2.h>
#else
#include <sys/socket.h>
#include <sys/types.h>
#include <sys/time.h>
#include <netinet/in.h>
#include <netdb.h>
#include <arpa/inet.h>
#endif
#include <sys/time.h>
#include <unistd.h>
#include <stdarg.h>
#include <stdio.h>
#include <string.h>
#include <stdlib.h>
#include <errno.h>
static int socket_fd = -1;
#define ASCII_DATA_PORT 9004
char dataBuffer[4096];
int main(void) {
struct sockaddr_in server;
struct hostent *hp;
char *ip_address = "192.168.20.10";
#ifdef __WIN32__
WSADATA version;
WORD mkword = MAKEWORD(2, 2);
int what = WSAStartup(mkword, &version);
if (what != 0) {
printf("Version not supported\n\n");
exit(-1);
}
#endif
/* Create socket */

Nortek Signature Series Specifications

General

Type	Acoustic Doppler Current Profiler (ADCP)
Operating Temperature	-5°C to +45°C
Storage Temperature	-20°C to +60°C
Temperature Sensor	Integrated
Pressure Sensor	Integrated
Compass and Tilt Sensor	Integrated
Data Storage	Internal memory
Communication Interfaces	Ethernet, RS-232
Depth Rating	Up to 6000 meters (depending on model)
Data Output	ASCII, binary
Beam Angle	Varies by model
Velocity Accuracy	±0.5% of measured velocity ±1 mm/s
