Data formats 65

unsigned short pressure : 1; // 0

unsigned short temp : 1; // 1

unsigned short compass : 1; // 2

unsigned short tilt : 1; // 3

unsigned short _empty : 1; // 4

unsigned short velIncluded : 1; // 5

unsigned short _unused1 : 1; // 6

unsigned short _unused2 : 1; // 7

unsigned short distIncluded : 1; // 8

unsigned short fomIncluded : 1; // 9

unsigned short _unused3 : 6;

} headconfig;

unsigned long serialNumber;

unsigned char year;

unsigned char month;

unsigned char day;

unsigned char hour;

unsigned char minute;

unsigned char seconds;

unsigned short microSeconds100;

unsigned short soundSpeed; ///< resolution: 0.1 m/s

short temperature; ///< resolution: 0.01 degre

Celsius

unsigned long pressure;

unsigned short heading;

short pitch;

short roll;

unsigned short beams_cy; ///< bit 15-12: Number of beams,

bit 11-10: coordinate system

unsigned short cellSize;

unsigned short blanking;

unsigned short velocityRange;

unsigned short battery;

short magnHxHyHz[3]; ///< Magnetometer Data

short accl3D[3]; ///< Accelerometer Data

unsigned int ambVelocity;

t_BottomTrackDataSetDescription4Bit DataSetDescription4bit; /*

unsigned short */

unsigned short transmitEnergy;

char velocityScaling;

char powerlevel;

short magnTemperature;

short rtcTemperature;

unsigned long error;

t_BottomTrackstatus status; /* Unsigned long */
