Installation guidelines
3-39
User Guide Rel 1.0 Standard May 1999
Procedure 3-12 (continued)
Installing batteries
Battery options
Table 3-3 lists the battery options
You can use your own external battery vault instead of the provided battery
compartment underneath the equipment compartment. The cabinet is equipped
in the AC compartment with knockout panels. To install battery cables through
the knockouts (see Procedure 3-13, “Installing battery cables from an external
vault”).
Action
Step Action
1
Install the batteries into the front and rear partitions of the battery
compartment (see Figure 3-24, Figure 3-25, and Figure 3-26).
Note:
The cabling color designation is RED = negative (-) and BLACK =
positive (+).
—continued—
Table 3-3
Battery options
PEC Description Quantity
A0734525 Battery single block C&D FA-12-100 See Note 1 and 2
A0774151 Battery string hook up cable 1 for each string
A0773445 Battery single block East Penn
12AVR100-3ET
See Note 1 and 2
A0774150 Battery string hook up cable 1 for each string
A0773443 Battery single block Power Battery
CSL-12100
See Note 1 and 2
A0774150 Battery string hook up cable 1 for each string
Note 1:
One string must contain 4 single battery blocks.
Note 2:
672 lines provided: 4 strings are required. 864 lines provided: 5
strings are required. 1344 lines provided: 6 strings are required. 2016 lines
provided: 8 strings are required.
