6-20
Ordering information
AN2016 Cabinet User Guide Rel 1.0 Standard May 1999
Table 6-5 lists the standard equipment for an expansion kit from 672- to
2016-line cabinet. For the equipment frame/bay layouts and mounting
positions, see Figure 6-8, Figure 6-10, Figure 6-11 and Figure 6-12.
NT7E44JC CNet bay cable provides communication links between ABM
shelves
1
NTNR80AA 14 pair cable assembly provides DS1 connectivity between
AccessNode and DSX panel
2
NTNR80BA 28 pair cable assembly provides DS1 connectivity between
AccessNode and DSX panel
2
NTNR90AA Distribution power cable used to power up the CDS shelves 1
NTNR90BA Cable kit to power up the CDS shelves 1-7 talk batteries 1
P0902427 Cabinet label kit 1
Required options to order
B01231144 NT5C06CA-3 MPR 25 rectifier module (see Notes 1 and 2) 1 or 2
Note 1:
Insert appropriate number of modules into rectifier shelves NT5C10CP-61 part of NTNR21AA.
Note 2:
Three modules total are required for 1344 lines + (1) for redundancy.
Note 3:
Refer to “Optional battery backup” on page 6-45 for ordering battery string hook up cables,
required when the battery compartment holds the battery backup.
Note 4:
Refer to “ Optional remote monitoring unit” on page 6-44 for ordering RMU test access path
cable when optional RMU NTNR35AA is selected. A cable must be ordered for each additional AN ABM
NTNR10AA.
—end—
Table 6-5
672- to 2016-line expansion kit equipment (standard) for AN2016 Cabinet
PEC Description Quantity
NTNR10AA includes AccessNode hardware kit 2
Note:
A second ABM is required to support the additional CDS shelves.
NT4K14AB Breaker interface panel 1
NT4K1490 Breaker interface front cover assembly 1
NT4K16CA Local craft access panel, modular business package 1
NT4K10AB Access common equipment shelf 1
—continued—
Table 6-4 (continued)
672- to 1344-line expansion kit equipment (standard) for AN2016 Cabinet
PEC Description Quantity
