HQGL[ ( &%( &RQWURO%
(YHQW
Equation Entry
88 AFC-600 Programming PN 51032:A 3/8/99
(TXDWLRQ(QWU\
The equations are entered in the Veri•Fire 600 Upload/Download program.
/R
LF)XQFWLRQV
7KH ´$1'µ 2
HUDWRU
Requires that each arguement be in alarm.
Example: AND(Z02,Z05,Z09)
All three arguments in the equation must be in alarm for the control module to be
activated
.
7KH ´25µ 2
HUDWRU
Requires that any argument be in alarm
Example: OR(Z02,Z05,Z09)
If any one of the three arguments in the equation is in alarm the control module will be
activated.
7KH ´127µ 2
HUDWRU
Inverts the state of the argument (activated to deactivated OR deactivated to activated).
Example: NOT(Z02)
The control module will remain activated until the arguement comes into alarm.
If the argument goes into alarm the control module will deactivate.
7KH ´21/<µ 2
HUDWRU
Requires only one argument be in alarm.
Example: ONLY1(Z02,Z05,Z09)
If only one of the arguments is in alarm the control module will be activated.
7KH ´$1<µ 2
HUDWRU
Requires that two or more arguments be in alarm.
Example: ANY2(Z02,Z05,Z09)
If any two or more of the arguments are in alarm the control module will be activated.
7KH ´$1<µ 2
HUDWRU
Requires that three or more arguments be in alarm.
Example: ANY3(Z02,Z05,Z07,Z09)
If any three or more of the arguments are in alarm the control module will be activated.
7KH ´;=21(µ 2
HUDWRU
Requires that any combination of two or more devices programmed to zone be in alarm.
Example: XZONE(Z02)
If any combination of two or more initiating devices that have been programmed (CBE)
to this software zone comes into alarm, then this control module will be activated.
