Detector Sensitivity Settings
$
SS
HQGL[ & $:$&6 $
SS
OLFDWLRQV
AFC-600 Programming PN 51032:A 3/8/99 79
'HWHFWRU6HQVLWLYLW\6HWWLQJV
+RZWR6HOHFW3UH$ODUPDQG$ODUP6HQVLWLYLW
\
Each detector provides a host of selectable intelligent options. You can program
Pre-Alarm and Alarm detector sensitivity levels (Table 40) in the widest allowed ranges
(0.03 to 4% obscuration per foot). The AFC-600 provides nine levels of Pre-Alarm
(PA:1–PA:9) and Alarm (AL:1–AL:9) in percent per foot obscuration:
•
PA:0
no Pre-Alarm selection
•
PA:1
the self-optimizing setting where the control panel selects a suitable
Pre-Alarm level for a detector
•
PA:2–PA:9
the detector Pre-Alarm sensitivity level—with PA:2 the most sensitive
and PA:9 the least sensitive
•
AL:1–AL:9
the detector Alarm sensitivity level—with AL:1 the most sensitive
and AL:9 the least sensitive
7DEOH  'HWHFWRU 6HQVLWLYLW
\
LQ
S
HUFHQW REVFXUDWLRQ
S
HU IRRW
Detector Type Alarm
Pre-Alarm
Photo Electric
SMOKE (PHOTO)
SDX-551/SDX-751
(See note 3)
AL:1=0.50 %
AL:2=0.73 %
AL:3=0.96 %
AL:4=1.19 %
AL:5=1.43 %
AL:6=1.66 %
AL:7=1.89 %
AL:8=2.12 %*
AL:9=2.35 %
PA:1 =A uto
PA:2=0.30 %
PA:3=0.47 %
PA:4=0.64 %
PA:5=0.81 %
PA:6=0.99 %
PA:7=1.16 %
PA:8 =1 .3 3 %*
PA:9=1.50 %
Ion
SMOKE (ION)
CPX-551/CPX-751
(See note 3 & 4)
AL:1=0.50 %
AL:2=0.75 %
AL:3=1.00 %
AL:4=1.25 %
AL:5=1.50 %
AL:6=1.75 %*
AL:7=2.00 %
AL:8=2.25 %
AL:9=2.50 %
PA:1=Auto
PA:2=0.40 %
PA:3=0.50 %
PA:4=0.75 %
PA:5=1.00 %
PA:6 =1 .2 5 %*
PA:7=1.50 %
PA:8=1.75 %
PA:9=2.00 %
Laser
SMOKE (LPX)
LPX-751
AL:1=0.03 %
AL:2=0.05 %
AL:3=0.10 %
AL:4=0.20 %
AL:5=0.30 %
AL:6=0.50 %*
AL:7=0.70 %
AL:8=0.80 %
AL:9=1.00 %
PA:1 =A uto
PA:2=0.02 %
PA:3=0.03 %
PA:4=0.05 %
PA:5=0.10 %
PA:6 =0 .2 0 %*
PA:7=0.30 %
PA:8=0.40 %
PA:9=0.50 %
Multi Sensor
MULTISENSOR
IPX-751
AL:1=0.71 %
AL:2=0.71 %
AL:3=1.00 %
AL:4=1.00 %
AL:5=2.00 %*
AL:6=3.00 %
AL:7=3.00 %
AL:8=4.00 %
AL:9=4.00 %
PA:1 =0 .7 1%
PA:2=0.71 %
PA:3=0.50 %
PA:4=1.00 %
PA:5 =1 .0 0 %*
PA:6=2.00 %
PA:7=2.00 %
PA:8=3.00 %
PA:9=3.00 %
Notes:
1. * Signifies the factory default setting.
2. The use of alarm sensitivities below 0.50% obscuration per foot requires a 90 day test to ensure that the
environment for the detectors is suitable for the higher sensitivity setting. (Refer to “How to Test Detectors Set
Below 0.50% Obscuration per Foot” on page 80.)
3. Suitable for open area protection only with 0 to 300 feet per minute air velocity.
4. Use only Alarm sensitivity setting of AL=1, AL=2 or AL=3 for Ion detectors installed in Canada.
