Notifier AFC-600 Programming Manual

Type Codes for Output Devices
$
SS
HQGL[ * 7
\S
H &RGHV
AFC-600 Programming PN 51032:A 3/8/99 99
7\SH&RGHVIRU2XWSXW'HYLFHV
2YHUYLHZ
This section provides Type Codes for control modules, NACs, and Panel Circuits. For
instructions on programming Type Codes, refer to "How to Modify or Delete a Point
(2=
POINT
)" on page 21.
7
\S
H&RGHVIRU&RQWURO0RGXOHV
Table 47 contains a comprehensive list of control module Type Codes, which you can
select to change the function of a control module point. The Type Codes that display,
however, depend on the configuration.
7DEOH  &RQWURO 0RGXOH 7
\S
H &RGHV
Type Code Configuration Function
CONTROL
NAC Supervised NAC
RELAY
Form-C relay Relay output
BELL CIRCUIT
NAC Supervised NAC for notification appliance
STROBE CKT
NAC Supervised NAC for notification appliance
HORN CIRCUIT
NAC Supervised NAC for notification appliance
AUDIBLE CKT
NAC Supervised NAC for notification appliance
SPEAKER
NAC Supervised NAC for notification appliance
REL END BELL
NAC Supervised NAC for notification appliance
blank label NAC Supervised NAC (use when no other Type
Code applies)
RELEASE CKT
NAC Releasing Circuit, nonpower-limited,
supervised for opens and ground faults
(always non-silenceable)
REL CKT ULC
NAC Releasing circuit, power-limited,
supervised for opens, shorts and ground
faults
RELEA
.
FORM C
Form-C relay Relay output, contacts operate upon release
REL AUDIBLE
NAC NAC, activated upon release
NONRESET CTL
Form-C relay and
NAC
Relay output, unaffected by “System
Reset” command
TELEPHONE
NAC Standard telephone circuit
INSTANT RELE
NAC NAC, short=normal; supervised for open
circuits and ground faults. Always non-
silenceable and switch-inhibited.
