Notifier AFC-600 Programming Manual

$
SS
HQGL[*7
\S
H &RGHV
Type Codes for Input Devices
98 AFC-600 Programming PN 51032:A 3/8/99
SYSTEM RESET
1
(non-latching)
alarm point that
activates CBE
Provides a function for resetting
the control panel (as if pressing the
SYSTEM RESET
key) using a remote
switch, such as the AKS-1.
EVACUATE
1
(latching)
alarm point that
activates CBE
Provides a function for activating
alarms (as if pressing the
ALARM
ACTIVATE
key) using a remote
switch, such as the AKS-1.
PAS INHIBIT
2
(latching)
alarm point that
activates CBE
Provides a function, required by
NFPA 72-1993, to override a
programmed PAS function for the
point programmed for Presignal
(Special Function F0).
TROUBLE MON
(non-latching)
does not activate
CBE
Monitors trouble contacts on
devices external to the system for a
short or open circuit. If the point
activates, a trouble occurs at the
control panel.
SECURITY
(latching)
alarm point that
activates CBE
Monitors the point for a short or
open circuit. If the point activates, a
Security alarm occurs at the control
panel.
TELE
.
PAGE
(non-latching)
alarm point that
activates CBE
Enables remote paging to a fire
area if a Voice Alarm System is
installed.
ALLCALL PAGE
(non-latching)
alarm point that
activates speakers
Enables paging though all
connected speakers from a remote
phone in the installation.
MAN REL DELAY
(latching)
alarm point that
activates CBE
Initiates manual release with
10-second delay, that supplants the
programmed timers.
SECOND SHOT
(latching)
alarm point that
activates CBE
Reactivates release output for
second agent discharge after an
initial release.
SPRINKLR SYS
(latching)
alarm point that
activates CBE
Monitors a waterflow device.
COMB
.
MONITOR
(latching)
alarm point that
activates CBE
Provides waterflow and
supervisory monitoring on same
monitor module.
1. These Type Codes provide system control functions for remote key
switches. If using these functions, protect the key switches from
unauthorized use by installing a key switch in a lockable cabinet.
2. For detailed information on the PAS function, refer to "Presignal and
Positive Alarm Sequence (PAS)" on page 69.
Type Code Label Point Function Function of the Type Code
7DEOH  0RQLWRU 0RGXOH 7
\S
H &RGHV &RQWLQXHG
