Type Codes for Input Devices
$
SS
HQGL[ * 7
\S
H &RGHV
AFC-600 Programming PN 51032:A 3/8/99 97
7
\S
H&RGHVIRU0RQLWRU0RGXOHV
Table 46 lists monitor module Type Codes, which you can use to change the function of
a monitor module point.
Type Code Label Point Function Function of the Type Code
MONITOR
(latching)
alarm point that
activates CBE
The default monitor module Type
Code for monitoring conventional
fire alarm devices.
PULL STATION
(latching)
alarm point that
activates CBE
Monitor manual fire stations, such
as BG-1 and BNG-1.
SMOKE DETECT
(latching)
alarm point that
activates CBE
Monitors two-wire and four-wire
smoke detectors.
HEAT DETECT
(latching)
alarm point that
activates CBE
Monitors conventional thermal
detectors.
blank (12 spaces) alarm point that
activates CBE
Monitors undefined alarm devices.
WATERFLOW
(latching)
alarm point that
activates CBE.
If
activated, this Type
Code causes a non-
silenceable alarm
Monitors waterflow alarm switches
for alarm points.
SUPERVISORY
(non-latching)
alarm point that
activates CBE
Monitors waterflow tamper
switches for alarm points.
TAMPER
(latching)
alarm point that
activates CBE
Monitors waterflow tamper
switches for alarm points.
NON FIRE
(nonlatching)
non-alarm point that
activates CBE
Monitor energy management
devices for non-alarm points.
HAZARD ALERT
(latching)
non-alarm point that
activates CBE
Monitor critical items
Note: Use for a non-alarm point.
FIRE CONTROL
(non-latching)
non-alarm point that
activates CBE
Monitor air handler shutdown;
does not pulse the panel sounder.
ABORT SWITCH
(nonlatching)
alarm point that
activates CBE
For a monitor module connected to
a UL-listed abort station, an
activated module aborts the release
zone, like a conventional abort
switch on a conventional zone. You
can also program multiple monitor
modules as abort switches.
MAN
.
RELEASE
(latching)
alarm point that
activates CBE
Performs a manual release function
that overrides all active monitor
modules, connected to a UL-listed
manual station programmed with
ABORT SWITCH
Type Code.
SILENCE
1
(non-latching)
alarm point that
activates CBE
Provides a function for silencing
alarms (as if pressing the
ALARM
SILENCE
key) using a remote
switch, such as the AKS-1.
7DEOH  0RQLWRU 0RGXOH 7
\S
H &RGHV
