How to Program a Releasing Zone
54 AFC-600 Programming PN 51032:A 3/8/99
8VLQ
J
7
\S
H&RGHVIRU5HOHDVLQ
J
=RQHV
The control panel provides a set of Type Codes designed for releasing applications for
inputs (Table 31) and outputs (Table 32). This section details how to program each of
these Type Codes.
Table 31 lists Type Codes designed for Releasing Zone inputs (monitor modules).
7DEOH  7
\S
H &RGHV IRU 5HOHDVLQ
J
=RQH ,Q
S
XWV
Table 32 lists the Type Codes designed for Releasing Zone outputs (control modules,
NACs, and Panel Circuits).
7DEOH  7
\S
H &RGHV IRU 5HOHDVLQ
J
=RQH 2XW
S
XWV
Type Code What the Type Code does Refer to
ABORT SWITCH
(tracking)
Provides an abort function through a
monitor module (connected to a
UL-listed abort station) for a
Releasing Zone.
"How to Program an Abort Switch"
on page 55
MAN
.
RELEASE
(latching)
Provides a manual release through a
monitor module (connected to a
UL-listed pull station) for a
Releasing Zone.
"How to Program a Manual Release
Switch" on page 56
MAN REL DELAY
(latching)
Provides a manual release with
a 10-second delay through a
monitor module (connected to a
UL-listed pull station) for a
Releasing Zone.
"How to Program a Manual Release
Delay Switch" on page 57
SECOND SHOT
(latching)
Provides a second manual
release through a monitor
module (connected to a
UL-listed pull station) for a
Releasing Zone.
"How to Program a Second Shot
Switch" on page 58
Type Code What the Type Code does Refer to
REL END BELL
Activates an NAC audio or visual
device when releasing circuits shut
off.
"How to Program a Release End Bell
Circuit" on page 59
REL CKT ULC
Directs outputs to perform a release
function as required by ULC.
"How to Program a ULC Release
Circuit" on page 60
RELEASE CKT
Directs outputs to perform a releasing
function.
"How to Program a Release Circuit"
on page 61
RELEA
.
FORM C
Directs relay outputs to perform a
releasing function.
"How to Program a Release Form-C
Circuit" on page 62
REL AUDIBLE
Activates audio or visual devices to
steady when releasing starts.
"How to Program a Release Audible
Circuit" on page 63
INSTANT RELE
Activates non-releasing output with
no delay time.
"How to Program an Instant Release
Circuit" on page 64
REL CODE BELL
Activates audio or visual devices to
pulse at 120 ppm (Delay Timer
activation) or 20 ppm (Cross Zone
activation).
"How to Program a Release Code
Bell Circuit" on page 65
