Wiring Speaker Circuits
9RLFH $ODUP 6\VWHP
AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 4-29
:DWW(LJK W6 SH DNHU&LUFXLW&RQ IL JX UDWLRQ
:LULQJ 1RWHV
When wiring eight speaker circuits using 90 watts of power, note the following:
1. The AA-30 supplies audio power through plug P6, or terminals 5 and 6 on terminal
block P8. (This audio power run is not supervised.) If using the optional
supervised return, a loss of audio power (due to a break in the wiring) will generate
a trouble signal at the AA-30.
2. If using an optional supervised four-wire return, cut resistors R8 and R9, located
directly below plug P6 on the AA-30.
3. Each circuit can handle a maximum of 30 watts.
4. In the configuration shown below, cut VCE-4 jumpers JP1 and JP2.
:LULQJ 'LDJUDP
Figure 4-35 shows typical wiring for a 90-watt (VCM-4 provides 30 watts and the
VCE-4 provides 60 watts for a total of 90 watts), eight-speaker circuit:
)LJXUH 7\SLFDO :DWW (LJKW6SHDNHU &LUFXLW
ZDWWV RQ
WZR FLUFXLWV
ZDWWV RQ
WZR FLUFXLWV
ZDWWV
ZDWWV ² 7KHVH IRXU
FLUFXLWV VKDUH ZDWWV
2SWLRQDO VXSHUYLVHG
5HWXUQ 1RWH
2SWLRQDO VXSHUYLVHG
5HWXUQ 1RWH
3
3
3
3
3
3
