Notifier AFP-400 Installation Manual

 9RLFH $ODUP 6\VWHP Wiring Speaker Circuits
4-32 AFP-300/AFP-400 Installation PN 50253:C1 05/22/97
:DWW'XDO&KDQQHO&RQILJXUDWLRQ
:LULQJ 1RWHV
When wiring circuits in a dual-channel configuration using 30 watts of power, note the
following:
1. Plug P6 or terminals 5 and 6 of terminal block P8 provide AA-30 audio power.
This audio power run cannot be supervised in this configuration.
2. Maximum power is 30 watts per circuit.
3. For dual-channel operation, cut VCE-4 jumpers JP1 and JP2 (Figure 4-38).
:LULQJ 'LDJUDP
Figure 4-38 shows typical wiring for a 30-watt, dual-channel configured circuit:
)LJXUH  7\SLFDO :DWW 'XDO &KDQQHO & RQILJXUDWLRQ
 ZDWWV ² 7KHVH IRXU FLUFXLWV VKDUH
 ZDWWV HDFK
)RU GXDOFKDQQHO
RSHUDWLRQ FXW MXPSHUV
-3 DQG -3
