AFP-300/AFP-400 Installation PN 50253:C1 05/22/97 D-1
$SSHQGL['&57&R QILJXUDWLRQ
2YHUYLHZ
The CRT-2 communicates with the control panel through a protocol defined by thirteen
groups of parameters. To access a parameter group, press the corresponding function
key (F1-F13) as shown in Table D-1. You can then program parameters in each group.
6HWWLQJ&573 DUDPHWHUV
Enter the CRT-2 setup menu by pressing and holding the <Ctrl> key while pressing the
<Scroll Lock> key. Use arrow keys to move through the selections in each setup group;
press the space bar to view the options for each parameter. When finished
programming all setup groups, press the <Pause> key. To save all changes, press <Y>.
7DEOH ' &57 )XQFWLRQ .H\V DQG 3DUDPHWHUV
Function
Key
CRT-2 Parameters
F1: Quick Emulation=CRT-2
Comm Mode=Full Duplex
Enhanced=On
EIA Baud Rate=2400
Aux Baud Rate=2400
Language=U.S.
EIA Data Format=8/1/N
Aux Data Format=7/1/E
Host/Printer=EIA/Aux
F2:Genrl Emulation=CRT-2
Auto Font Load=On
Monitor Mode=Off
Host/Printer=EIA/Aux
Enhanced=On
Auto Page=Off
Bell Volume=09
Auto Wrap=Off
Auto Scroll=On
Warning Bell=On
F3: Displ Page Length=24
Display Cursor=On
Columns=80
Scroll=Jump
Screen Length=26 Lines
Cursor=Blink Line
Width Change Clear=Off
Refresh Rate=60 Hz
Screen Video=Normal
Auto Adjust Cursor=On
Speed=Normal
Overscan Borders=Off
F4: Kybd Language=U.S.
Keyclick=Off
Key Lock=Caps
Char Set Mode=ASCII
Key Repeat=Off
Keyboard Present=Yes
Key Mode=ASCII
Margin Bell=Off
F5: Keys Enter Key=<CR>
Alt Key=Meta
Pound Key=U.S.
Return Key=<CR>
Disconnect=Pause
Backspace=<BS>/<DEL>
Desk Acc=Disabled
F6: Ports EIA Baud Rate=2400
Aux Baud Rate=2400
EIA Xmt=Xon-Xoff
Aux Xmt=Xon-Xoff
EIA Break=Off
Aux Break=Off
EIA Data Format=8/1/N
Aux Data Format=7/1/E
EIA Recv=Xon-Xoff(XPC)
Aux Recv=Xon-Xoff(XPC)
EIA Modem Control=Off
Aux Modem Control=Off
EIA Parity Check=On
Aux Parity Check=On
EIA Xmt Pace=Baud
Aux Xmt Pace=Baud
EIA Disconnect=2 sec
Aux Disconnect=2 sec
F7: Host Comm Mode=Full Duplex
Recv <DEL>=Ignore
Send Block Term=<CR>
Local=Off
Send ACK=On
Null Suppress=On
Recv <CR>=<CR>
Send Line Term=<CR><LF>
F8: Print Prnt Line Term=<CR><LF> Prnt Block Term=<CR> Secondary Recv=Off
F9: Emul Attribute=Page
WPRT Intensity=Dim
WPRT Blink=Off
Status Line=Off
Bright Video=Off
WPRT Reverse=Off
Display NV Labels=Off
Fkey Speed=Normal
Page Edit=Off
WPRT Underline=Off
Save Labels=On
F10 Setup Group F10 does not affect communications with the control panel.
F11 Setup Group F11 does not affect communications with the control panel.
F12: Prog Program the function keys as follows:
F1 ~A F2 ~B F3 ~C F4 ~D F5 ~E F6 ~F F7 ~G F8 ~H F9 ~I F10 ~J F11 ~K F12 ~L F13 ~M
F14 ~N F15 ~O F16 ~P Shift F13 ~Q
