Notifier IFS-2600 User Manual

IFS-2600 Fire Indicator Panel Section 2 System Overview
DOC-01-009 6
Qty Descriptor Colour Function Buzzer
1 MAINS ON Green Illuminates when there is AC supply to the panel.
1
BATTERY
FAULT
Yellow
Illuminates if the battery fails a battery test.
Illuminates if batteries are disconnected >30 seconds.
Illuminates if batteries are short circuit >30 seconds.
Yes
1 PSU FAULT Yellow
Illuminates if the power supply is outside the manufacturers
range. (Also if power supply is disconnected)
Yes
1
CHARGER
FAULT
Yellow
Illuminates if the battery charger is outside the
recommended float charge voltage.
Yes
1
COMMON
FAULT
Yellow
Illuminates if there is Any fault;
 Any un-isolated zone is in open circuit fault.
 ACF output is open or short circuit
 Bell output is open or short circuit
 Warning System output is open or short circuit
 Power Supply Fault including Battery or Charger
 MAF Isolate Input is Open Circuit
 Configuration Fault
Yes
1 ACF ACT Red Illuminates if the ACF output has been activated.
1 ACF FLT Yellow Illuminates if the ancillary circuit is open or short circuit. Yes
1 ACF ISO Yellow
Illuminates if the ancillary output has been manually
isolated.
1 Bell ACT Red Illuminates when the bell output has been energised.
1 Bell FLT Yellow Illuminates if the bell circuit is open or short circuit. Yes
1 Bell ISO Yellow Illuminates if the bell output has been manually isolated.
1
Warning
System ACT
Red
Illuminates if the Warning System output has been
energised.
1
Warning
System FLT
Yellow
Illuminates if the Warning System circuit is open or short
circuit.
Yes
1
Warning
System ISO
Yellow
Illuminates if the Warning System has been manually
isolated.
8
ALARM
LEDS
Red
This LED will flash if its corresponding zone goes into
alarm. It will remain flashing until it is Acknowledged at
which time it will go steady and remain on until the alarm is
reset. If the zone is programmed as a time delay type, a
steady LED indicates the “pre-alarm” condition. If the zone
is isolated and in alarm it will also be steady.
Yes
8 FAULT LEDS Yellow
This LED illuminates if it's corresponding zone goes into
fault. It will remain on until the fault is removed.
Yes
8
ISOLATE
LEDS
Yellow
This LED illuminates if its corresponding zone is isolated. It
will remain on until the zone is de-isolated.
Table 2-2, Key Pad Description
