IFS-2600 Fire Indicator Panel Section 2 System Overview
DOC-01-009 4
2.5. LCD Display
In addition to the LED's a 16-character x 2-line liquid crystal display is provided to indicate system status,
changing events and programming information. Any keystroke or event will actuate the backlighting on
the display for better readability in dark areas. The backlighting will automatically turn off in 30 seconds if
no further keys are pressed.
The primary task of the LCD is for programming and subsequent configuration of the fire indicator panel.
The LCD is also used to indicate the current mode of operation, e.g. "ISOLATE MODE", "ALARM TEST
MODE" etc. The LCD is also used as a prompt for user entries e.g. "ENTER ZONE #".
When the panel is in the normal mode of operation, the LCD displays and constantly updates the current
zone status including the total number of;
Zones In Alarm – A=00
Zones In Fault – F=00
Zones Isolated – I=00
Current Date
Current Time (As per the settings)
