DOC-01-009 48
Use the "NEXT" & "PREVIOUS" keys to change the first relay to start from, together with the matching
zone. Use the “ENTER” key to toggle between the two and press “SELECT” once finalised. “Exit” will
abort unity map.
This function will start programming relays starting from the relay number specified in a 1 to 1 configuration
with zones starting from the first zone number specified.
Example 1: if the above table was to look like this:
MAP RELAY (10) >>
FROM ZONE (01)
Then relay #10 would be set as MAP OR with its mapping as (01) 00 00 00 00, relay #11 would be set as
MAP OR with it’s mapping set as (02) 00 00 00 00 and so on all the way up to relay #64. Relays number
1-through 9 remains unaffected by this function.
Example 2: if the above table was to look like this:
MAP RELAY (01) >>
FROM ZONE (09)
Then relay #1 would be set as MAP OR with its mapping as (09) 00 00 00 00, relay #2 would be set as
MAP OR with it’s mapping set as (10) 00 00 00 00 and so on all the way up to relay #64.
Date & Time
The current DATE & TIME will be displayed as DD/MM/YY (in 24h format)
Use the PREVIOUS” & NEXT” keys to increment or decrement the number highlighted by brackets.
The ENTER key will move to the next field.
When finished, the SELECT key must be pushed to store the date/time.
5.5. Print Programming Data
Prints the programming data currently stored in RAM, including all changes made (they may have not yet
been written to the E2ROM).
Output is printed directly onto the serial printer if fitted.
NOTE:
In example 2, zone number 64 is reached and there are still more relays to go. (i.e. we
are only at relay #56) the programming stops at this point and any relays not yet
programmed will be left in their previous programmed mode and are unaffected by this
function.
NOTE:
The Date/Time data is saved when the Select key is pushed.
DO NOT select “Save Changes “Y” as this will restart (and drop any door holders / air-
conditioning if connected).
