DOC-01-009 46
5.4. Global Options & Programming
There are four global options that can be programmed:
(ACF) AVF
RELAY TIME
Use the "NEXT","PREVIOUS" & "SELECT" keys to select.
Pressing "EXIT" will return to "Main Menu".
Ancillary Control Facility (ACF)
ACF OUTPUT
(NON-LATCH ND)
The ancillary trip is used for the shutting down of air conditioning and other systems in the event of a fire.
Global Programmable Options:
Ancillary Trip (ACF)
1 LATCHING NORMALLY DE-ENERGISED
2 NON-LATCHING NORMALLY DE-ENERGISED
3 LATCHING NORMALLY ENERGISED
4 NON-LATCHING NORMALLY ENERGISED
The ancillary trip can be programmed as latching or non- latching depending on the application.
It call also be programmed as normally energised or normally de-energised.
If a zone is programmed to operate the ancillary trip, an alarm condition will energise the ancillary trip until
the alarm is removed (if non-latching), or until the alarm is removed and the ACF is manually reset via the
keypad (latching).
Use the "NEXT" & "PREVIOUS" keys to scroll through:
LATCHING ND
NON-LATCH NE
LATCHING NE
ND = Normally De-energised i.e.: Output is not energised until an alarm occurs.
NE = Normally energised i.e.: Output is energised and then is de-energised once an alarm occurs
NOTE:
The option previously set is displayed in brackets and is the first to be displayed.
