Notifier IFS-2600 User Manual

IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 14
3.5. Standard Outputs
Output Type Description
Standby

Change
over relay
contact
Normally energised relay: Will de- energise if system volts fall below 21V. This
usually means AC has failed and batteries are getting low. I.e. panel is about
to shut down.
Brigade
Alarm #1
Change
over relay
contact
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non- isolated zone(s) in alarm. (Programmable)
Brigade
Alarm #2
Change
over relay
contact
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non- isolated zone(s) in alarm. (Programmable)
Fault
Change
over relay
contact
Normally energised relay: Will de-energise if a common fault is registered.
Mains Fail
(NV)
Change
over relay
contact
Normally energised relay: Will de-energise if the AC fails
Isolate
Change
over relay
contact
Normally de-energised relay: Will energise if any zones are isolated.
General
Alarm 1
Change
over relay
contacts
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non-isolated zone(s) in alarm. (Non-Programmable)
General
Alarm 2
Change
over relay
contacts
Normally de-energised relay: Will energise if requested by the zone output
configuration of the non-isolated zone(s) in alarm. (Non-Programmable)
Bell
Monitored
24 VDC
Output 1A
Fused
Normally de-energised: Output will energise if requested by the zone output
configuration of the non-isolated zone(s) in alarm. Will remain energised until
alarm is reset or warning system is isolated.
Warning
System
Monitored
24 VDC
Output 1A
Fused
Normally De-energised: Output, will energise if requested by the zone output
configuration of the non- isolated zone(s) in alarm.
Ancillary
(ACF)
24 VDC
Output 1A
Fused
If ancillary is set as non-latch: Ancillary will remain energised until alarm(s) is
reset.
If ancillary is set as latching: Ancillary will remain energised until ancillary is
manually reset from the keypad. Even if the zone has been reset.
Door
Holder
24 VDC
Output up
to 3A
Normally energised 24VDC output: Will de-energise on general alarm.
NOTE: This output is isolated through the ACF Isolate Function.
Auxiliary
Power
24 VDC
Continuous
Power output for use with ancillaries (500mA maximum).
Mimic
Outputs
Serial four
wire mimic
outputs
This output mimics the status of all alarm zones fitted on the panel to a remote
mimic panel in the building.
Table 3-1, Standard Outputs
NOTE:
 Normally energised (fail safe) relay
 Monitored circuit, EOL resistor or load is required.
