IFS-2600 Fire Indicator Panel Section 3 Operation
DOC-01-009 15
3.6. Relay Expansion Boards
The maximum number of boards that can be fitted is eight (i.e.: 64 relays). Each board contains 8
change-over relay outputs. Relays can be programmed to simulate:
Brigade Alarm Relay #1
Brigade Alarm Relay #2
Fault Relay
Mains Fail Relay
Isolate Relay
General Alarm Relays
Bell Output
Ancillary Output
Door Holder Output
Door Switch
Reset
or can be used to
3.7. Printer Output
Located on the main termination board, a portable serial printer may be connected to the DB9 serial port
provided.
Most standard IBM compatible serial printers are suitable for this operation, which uses hardware
handshaking and will be enabled automatically.
AND MAP”
“OR MAP”
“MAP FAULT”
“MAP ISOLATE”
“MAP ISO/FLT”
Up to 5 zones in Alarm
Up to 5 zones in Alarm
Up to 5 zones in Fault
Up to 5 zones in Isolate
Up to 5 zones in Fault or Isolate
