Notifier IFS-2600 User Manual

IFS-2600 Fire Indicator Panel Section 5
Programming
DOC-01-009 42
5.3. Relay Options & Programming
5.3.1. Relay Options
Optional Relays can be programmed to simulate:
 Isolate Relay
 ACF Output
 Brigade Relay #1
 Brigade Relay #2
 Fault Relay
 Mains Fail Relay
 General Alarm Relay
 Bell Output
 Door Holder Relay
 Door Switch
 Reset
Or Can Be Used To:
 "MAP AND" Up to 5 Zones in Alarm
 "MAP OR" Up to 5 Zones in Alarm
 “MAP FAULT” Up to 5 Zones in Fault
 “MAP ISOLATE” Up to 5 Zones in Isolate
 “MAP ISO/FAULT” Up to 5 Zones in Isolate/Fault
Relay Output Mapping
A total of 64 expansion relays can be fitted to the IFS-2600. Each relay can be individually programmed to
mimic any of the following;
Standard Outputs which may be mimicked:
ANCILLARY OUTPUT (ACF)
BRIGADE ALARM RELAY #1
BRIGADE ALARM RELAY #2
*
FAULT RELAY (NORMALLY ENERGISED)
*
MAINS FAIL RELAY (NV) (NORMALLY ENERGISED)
ISOLATE RELAY
GENERAL ALARM RELAYS
BELL OUTPUT
DOOR SWITCH
RESET
DOOR HOLDER RELAY
FAULT/ISOLATE
When mapping to a normally energised relay, take care to ensure that connections take into account the
normally energised state of the relay. Alternatively, the expansion relay(s) can be mapped to provide
customised logic to suit specific installations:
