IFS-2600 Fire Indicator Panel Section 5
Programming
DOC-01-009 41
ZONE Type
ZONE # ALL TYPE
STD LATCHING
Use the "NEXT" & "PREVIOUS" keys to scroll through
Once the desired option has been highlighted, pressing the "SELECT" button will select it. Making a
selection or pressing "EXIT" will return to zone selected.
A function of “BELL” also operates the WARNING SYSTEM.
ZONE Output Configuration
ZONE #ALL OUTPUT
IBGA BRIG 1&2
Use the "NEXT" & "PREVIOUS" keys to scroll through:
INDICATE
I BELL
IB GENERAL
IBG ACF OUT
IBGA BRIGADE 1
IBGA BRIGADE 2
IBGA BRIG 1&2
Once the desired option has been highlighted, pressing the "SELECT" button will select it. Pressing "EXIT"
at this stage will return to "Zone Selected"
A function of “BELL” also operates the WARNING SYSTEM.
STD LATCHING
STD LATCHING AVF
NON LATCH
NON LATCH 20S
TIME DELAY 10S
TIME DELAY 20S
TIME DELAY 30S
TIME DELAY 40S
TIME DELAY 50S
TIME DELAY 60S
NOTE:
The option previously set is displayed in brackets and is the first to be displayed.
Previously set options will not be displayed if "ALL" is selected.
NOTE:
The option previously set is displayed in brackets and is the first to be displayed.
Previously set options will not be displayed if "ALL" is selected.
