IFS-2600 Fire Indicator Panel Section 5
Programming
DOC-01-009 43
AND Mapping
AND MAPPING allows the relay output to be programmed for a combination of up to 5 zones, and only
after they ALL go into alarm, will the relay operate.
AND MAPPING is useful for applications which have special shutdowns, multiple risk Gas Facilities etc.
OR Mapping
OR MAPPING works similarly. This function will cause the relay to operate if any one of up to five (5)
zones go into alarm, the relay will operate.
If the relay map options are set as "01" "02" "03" "00" "00", zones 1 or 2 or 3 in alarm will cause the relay to
operate.
OR MAPPING is useful for applications which have special shutdowns, zoned mimic outputs etc.
FAULT Mapping
FAULT MAPPING works the same as OR mapping of alarm except it relates to the fault flag on each zone
instead of the alarm flag. This function will cause the relay to operate if any one of up to five (5) zones go
into fault.
If the relay map options are set as "01" "02" "03" "00" "00", then zones 1 or 2 or 3 going into fault, will
cause the relay to operate.
FAULT/ISOLATE Mapping
FAULT/ISOLATE MAPPING works the same as OR mapping of alarm except it relates to the fault/isolate
flag on each zone instead of the alarm flag. This function will cause the relay to operate if any one of up to
five (5) zones go into fault/put in isolate.
If the relay map options are set as "01" "02" "03" "00" "00", then zones 1 or 2 or 3 going into fault/ (or are
manually put in isolate) will cause the relay to operate.
ISOLATE Mapping
ISOLATE MAPPING works the same as or mapping of alarm except it relates to the isolate flag on each
zone instead of the alarm flag. This function will cause the relay to operate if any one of up to five zones is
put in isolate.
If the relay map options are set as "01" "02" "03" "00" "00", then zones 1 or 2 or 3, if put in isolate will
cause the relay to operate.
Default Settings
ACF OUTPUT NON-LATCHING, NORMALLY DE-ENERGISED
ALARM VERIFICATION (AVF) 3 MINUTES
TIME 1/1/11 11:11
ZONE TYPES STANDARD LATCH 2S
ZONE OUTPUT CONFIG I-B-G-A-BR1 & BR2
RELAY MAPPING MAP -OR-, MAPPING = 1 TO 1
IE: RELAY 1 = ZONE 1, RELAY 2 = ZONE 2.............
The IFS-2600 PANEL is self-configuring on power-up therefore it is not necessary to program the number
of relay boards.
Zone expansion boards fitted must have the correct jumper selected.
