IFS-2600 Fire Indicator Panel Section 4 Installation
DOC-01-009 18
Specification for IFS-2608 & IFS-2624:
Cabinet Zinc Sealed Steel 1.6mm, Powder Coated
Hinged Inner & Outer Door
Outside Dimensions 2608 (8 zones) 394mm H x 390mm W x 180mm D*
2624 (24 zones) 750mm H x 390mm W x 180mm D*
*Note: the depth quoted is including the door and break glass.
Fuses
(IFS-2005 & IFS-2006
Boards)
Panel Supply Fuse F1 M205 5A
Battery Charger Fuse F2 M205 3A
Battery Protection Fuse F3 Polyfuse 3A
External Supply Fuse F4 M205 7A
Door Holder Fuse F5 M205 3A
Aux Power Output Fuse F6 M205 1A Slow Blow
Bell Fuse F7 M205 1A
Warning System Fuse F8 M205 1A
ACF Fuse F9 M205 1A
AZF Circuits Current Limited 40mA
E.O.L Resistor on AZFs,
monitored outputs, Bells,
Warning system, ACF
4K7 Ohms
Table 4-2, IFS-2600 Panel Configuration
