IFS-2600 Fire Indicator Panel Section 4 Installation
DOC-01-009 34
Power up Checklist
Ensure batteries are disconnected
Turn mains switch to "on"
The "mains on" LED should light
Allow 15 seconds for the panel to perform its start up tests
Connect batteries
Pulsing Heartbeat on the Termination Board (For new Board only)
Functional Tests
Primary ac supply voltage: 200 or 220 or 240vac +10% as required
Charger output voltage without batteries: 27.3v dc
Keypad functional
Perform auto test
LED’s all functional
LCD backlight functional
LCD Screen (Display) functional
Zone fault detection
Zone alarm detection
Internal Buzzer operating
MCP loop wired to zone number 1(For new Board it is connected to +VE & -VE)
Test auxiliary power output
Test bell output
Test warning system output
Test ACF output
Test door holder output (optional)
Test bell output supervision
Test warning system output supervision
Test ACF output supervision
Test brigade alarm relay #1
Test brigade alarm relay #2
Test standby relay (normally energised)
Test fault relay (normally energised)
Test mains fail relay
Test isolate relay
Test general alarm relays (2)
Test relay boards (if fitted)
Test open collector output boards (if fitted)
Press battery test button on Termination Board BTST/RST twice (For NI-2025-01 &
NI-2017-01 boards only)
If batteries are flat, allow 24hrs to charge and then re-test
