IFS-2600 Fire Indicator Panel Section 6 Appendix
DOC-01-009 51
MIMIC DATA & CLOCK
These outputs together with the mimic power terminals are used to serially communicate with the mimic
panels when fitted. EOL resistor is not required on these lines. (Refer to Section 4.5 for more details.)
AC INPUT (For IFS-2005 & IFS-2006 Boards only)
Mains step down transformer output (30VAC) is connected at these terminals. DO NOT connect 240VAC
to these terminals. (Refer to Section 4.4.2 for more details).
BATTERY
The 24V batteries are connected at these terminals. Reverse polarity will cause serious and permanent
damage to the equipment.
DOOR HOLDER INPUT
Terminate the door holder AC transformer at these terminals. 24 VAC is the only acceptable power source
at this point. DO NOT connect 240VAC at this point.
OUTPUT RELAYS
STANDBY (N) Normally energised, drops out when power supply (or battery supply) is below
specified voltage.
BRIGADE1 Brigade 1, defaults as energising on any alarm zone, programmable.
BRIGADE2 Brigade 2, defaults as energising on any alarm zone, programmable.
FAULT (N) Normally energised, drops out on any fault unless that function is isolated.
AC-FAIL (N) Normally energised, drops out if the mains power is lost.
ISOLATE Energised if any zone is isolated.
GENERAL1 Energised if any zone goes into alarm
GENERAL2 Energised if any zone goes into alarm
NOTE:
Firmware must be Version 6 or above for mimic operation.
