Notifier XPIQ User Manual

Power Supply Calculations Panel Programming
72 XPIQ PN 51013:C 7/01/03
Table 4.3 is used for calculating alarm current draw. Calculate the current and enter the total (in
amperes) in the bottom row. When finished, copy the totals from this table to Table 4.4.
Table Footnotes:
1. Include XPIQ-AA25/XPIQ-AA2270 backup amplifier when used as an external backup to XPIQs that have their
own batteries. These applications are shown in Figure 2.15 on page 40 and Figure 2.17 on page 42.
2. Other devices include devices separate from the XPIQ but backed up by the same battery: for example, APS-6R
used for NAC connected to the same battery as the XPIQ-PS(E).
Device Type Alarm Current in amperes
Qty X device current draw in amperes = total
XPIQ-PS(E)
Power Supply
1 X 0.022 =
XPIQ-MB
Mother Board
1 X 0.075 =
XPIQ-SLI
Signaling Line Interface
1 X 0.023 =
XPIQ-AA25 Primary Audio
Amplifier
[ ] X 2.125 =
XPIQ-AA25
used as external
backup
1
1 or 0 X 2.125 =
XPIQ-AA2270 Primary Audio
Amplifier
[ ] X 2.440 =
XPIQ-AA2270 used as external
backup
1
1 or 0 X 2.440 =
XPIQ-AIB1
Audio Input Board
[ ] X 0.011 =
XPIQ-AIB4
Audio Input Board
[ ] X 0.030 =
XPIQ-CA
Class A Converter Module
[ ] X 0.005 =
XPIQ-RMI
Remote Microphone Interface
[ ] X 0.009 =
RM-1(SA)
Remote Microphone
[ ] X 0.020 =
Alarm current draw of other
devices
2
[ ] X _____ =
Total Alarm Current sum of all current draws from right column =
Table 4.3 Alarm Current Draw Calculations
